technical parameter:
1. System voltage: 500V in DC3~950V in DC3
2. Rated operating frequency: 50/60Hz;
3. Fixed capacity: 1.5KW-630KW
4. Pressure drop: 1%-5%
5. Electric strength: core-winding 3000VAC/50HZ/10mA/10S without flying fox attack and wear;
6. Insulation resistance: core-winding 1000VDC, insulation resistance ≥100MQ;
7. Noise: <65 decibels (1 meter away from the transformer);
8. Overload: 1.5 times 1 minute 2 times 10S
9. Saturation characteristics: not less than 1.5 times of 80%
10. Protection class: IP00- IP65
11. Storage conditions: temperature 40°C~70C
12. Operating temperature: -30C~55C, derating above 50°C
13. Altitude application: The rated current is below 1000 meters, and the derating is more than 10% for each additional 100 meters per kilometer.
14. Products comply with UL/CSA/CE standards
15. Insulation class: F class H class.
16. The American DuPont Nomex paper is used as the insulating material, with high insulation grade and high withstand voltage
17. The iron core is made of silicon steel sheet, and the reactor has the characteristics of small size, high efficiency and low temperature rise.
18. Can be customized according to customer requirements
Size parameter table:
The above dimensions and characteristics are for reference only, we can set separately according to your requirements.
