■ Voltage specification table
|
Rated capacity |
one Φ 3KVA~20KVA & nbsp;& nbsp; three Φ 10KVA~150KVA |
|
|
input |
Rated voltage |
110V or 220V or 380V or 440V (or other special voltage) |
|
frequency |
47HZ—63HZ |
|
|
Voltage range |
±15% |
|
|
output |
Rated voltage |
110V or 220V or 380V or 440V |
|
Voltage stability |
± 1% - ± 3% (settable) |
|
|
Frequency stability |
Same as input power frequency |
|
|
Total harmonic distortion rate |
No distortion |
|
|
reaction time |
0.1-0.5 seconds (depending on voltage range) |
|
|
efficiency |
> 98% |
|
|
environment |
noise |
< 40dB |
|
temperature |
10 ° C-40 ° C (for indoor use) |
|
|
humidity |
0~95% |
|
■ Specification and size
|
type |
number |
frequency |
Frequency division description |
W H D |
|
|
GSW-1030 |
3KVA |
A.B.I |
A TYPE:110V |
19 27 42.5 |
|
|
GSW-1050 |
5KVA |
A.B.I |
22 28 49 |
||
|
GSW-1075 |
7.5KVA |
A.B.I |
B TYPE:220V |
22 28 49 |
|
|
GSW-1100 |
10KVA |
A.B.I |
22 28 49 |
||
|
GSW-1150 |
15KVA |
A.B.I |
I TYPE:110/220(1Φ3W) |
27 51 48 |
|
|
GSW-1200 |
20KVA |
A.B.I |
35 56 56 |
||
|
GSW-33075 |
7.5KVA |
X.X3.Y.I |
|
X TYPE input：3Φ3W 220V |
35 56 56 |
|
GSW-33100 |
10KVA |
X.X3.Y.I |
|
35 56 56 |
|
|
GSW-33150 |
15KVA |
X.X3.Y.I |
|
output：3Φ3W 220V |
35 56 56 |
|
GSW-33200 |
20KVA |
X.X3.Y.I |
|
X3 TYPE input：3Φ3W 380V |
35 56 56 |
|
GSW-33300 |
30KVA |
X.X3.Y.I |
|
35 56 56 |
|
|
GSW-33400 |
40KVA |
X.X3.Y.I |
|
output：3Φ3W 380V |
32 81 66 |
|
GSW-33500 |
50KVA |
X.X3.Y.I |
|
Y TYPE input：3Φ4W 380/220V |
45 94 84 |
|
GSW-33600 |
60KVA |
X.X3.Y.I |
|
45 94 84 |
|
|
GSW-33750 |
75KVA |
X.X3.Y.I |
|
output：3Φ4W 380/220V |
45 126 87 |
|
GSW-331000 |
100KVA |
X.X3.Y.I |
|
I TYPE input：3Φ3W 220V或380V |
45 126 87 |
|
GSW-331200 |
120KVA |
X.X3.Y.I |
|
45 126 87 |
|
|
GSW-331500 |
150KVA |
X.X3.Y.I |
|
output:3Φ4W 208/120Vor3Φ3W 380Vor220V |
45 126 87 |
Special specifications can be customized
