Product parameter
Technical characteristics:
1. The internal iron core uses high-quality, high silica steel sheets, the main material is selected with the most suitable high permeability, low loss material that meets customer requirements and conditions of use, to design transformer performance to optimal.
2. Internal insulation material is insulating using the American DuPont Nomex material, which has high temperature insulation, flame retardant and moisture resistance multiple properties.
3. Has stable voltage waveform, high impedance performance, low loss, low noise, has overload temperature protection, and machine circulation is small and shock resistance.
Technical parameters:
| Correctness of output voltage | ±1% |
| Output waveform distortion | No distortion (compared with input waveform) |
| Insulation grade | Class H |
| efficiency | More than 98% |
| frequency | 50-60Hz, 30hz-400hz can be designed according to customer requirements |
| capacity | 500W-200KVA |
| Electrical strength | Iron core winding 2500vac / 50Hz / 5mA / 10s without flashover breakdown |
| insulation resistance | 500VDC insulation resistance ≥ 200m Ω |
| Transformer noise | Less than 65dB (1m test from the horizontal distance point of transformer) |
| Degree of protection | IP00 |
| Insulation grade | Above grade F |
| Special specifications can be customized according to customer requirements |
